SOLID C-Band + C-Band Extended Wide Range C-Band LNBF
Partner Request
SOLID C-Band + C-Band Extended Wide Range C-Band LNBF
This is India's first C-Band Extended LNB which can receive signals from 3.7GHz to 4.8GHz. Usually, C-Band LNB comes in 3.7-4.2. This LNB is proudly tested on Bangabandhu Satellite which broadcasting TV channels on C-Band extended signals.
This LNB works on two L.O. or LNB Frequency (Normal C-Band and Extended C-Band)
Specifications -
For LO: 5150MHz
Noise Figure: 12K
Gain : 65dB
Input Frequency - 3.7~4.2GHz and also Receive 4.2GHz ~ 4.5GHz
Output Frequency - 950 ~ 1250MHz and 1250 ~ 1550MHz
For LO: 5750MHz
Noise Figure: 12K
Gain : 65dB
Input Frequency - 4.5GHz ~ 4.8GHz
Output Frequency - 1550 ~ 2050MHz
Specifications for L.O. 5150:
LO: 5750MHz
Noise Figure: 12K
Gain : 65dB
Input Frequency - 3.7~4.8GHz
Output Frequency - 950~2050MHz
Please note - You can use a single L.O. 5750 to receive all signals. No need to feed 5150 and 5950. It will work, we have tested it. You can Receive TV Signals from normal C-Band and Extended C-Band by fitting on C-Band Dish Antenna.
